Premium COB LED Display Solution
The DV Premier is a high-performance display that utilizes Chip On Board (COB) technology for improved stability, brightness, and durability. With a pixel pitch as low as 0.93 mm, it delivers stunning visuals with ultra-high contrast, vivid colors, and wide viewing angles. Designed for long-term reliability, it features low thermal resistance, energy-saving capabilities, and easy front maintenance for a hassle-free experience.
COB Technology
High Contrast & Color Consistency
170° Ultra-wide Viewing Angle
Ultra High Refresh Rate
Easy Front Maintenance
Immersive Visual Experience
COB Technology
Chip On Board (COB) is a technology where tiny LED chips are directly mounted onto a circuit board instead of being individually packaged. This design allows for a more compact arrangement, improving brightness, durability, and heat dissipation. As a result, COB displays offer better image quality, longer lifespan, and fewer technical failures compared to traditional LED screens.
170° Ultra-Wide
Viewing Angle
The DV Premier features an ultra-wide 170° viewing angle, ensuring that visuals remain clear and vibrant from almost any perspective. Even at extreme angles, there is no noticeable color shift, preserving image accuracy and consistency. The display’s delicate texture and smooth visuals create a comfortable and immersive viewing experience, making it ideal for various applications.
Ultra-High Contrast
Enhancing the contrast between light and shadow, the DV Premier delivers deeper blacks and more vivid highlights for a truly immersive viewing experience. Its advanced display technology brings out intricate picture details, ensuring every image appears sharp and lifelike. With a no-glare, low-reflection design, viewers can enjoy exceptional image quality in any lighting condition.
Immersive Visual Experience
With up to 800 nits of brightness, the DV Premier delivers vivid visuals that remain clear even in well-lit environments. Its 3840 Hz refresh rate ensures ultra-smooth motion, eliminating flicker for a comfortable viewing experience. Paired with 50/60 Hz frame rates, the DV Premier guarantees consistently fluid playback that keeps every audience engaged.
Specifications
| Pixel Pitch | 0.93 mm | 1.25 mm | 1.56 mm | 1.87 mm |
| LED Type | COB | COB | COB | COB |
| Module Size (inches) (W x H) | 11.81 x 6.64 | 11.81 x 6.64 | 11.81 x 6.64 | 11.81 x 6.64 |
| Module Resolution (WxH) | 320 x 180 | 240 x 135 | 192 x 108 | 160 x 90 |
| Cabinet Size - inches (W x H x D) | 23.62 x 13.29 x 1.57 | 23.62 x 13.29 x 1.57 | 23.62 x 13.29 x 1.57 | 23.62 x 13.29 x 1.57 |
| Cabinet Resolution (WxH) | 640 x 360 | 480 x 270 | 384 x 216 | 320 x 180 |
| Cabinet Weight | 8.6 lbs. | 8.6 lbs. | 8.6 lbs. | 8.6 lbs. |
| Max Brightness | 600-800 nits | 600-800 nits | 600-800 nits | 600-800 nits |
| Viewing Angle | 170°/170° | 170°/170° | 170°/170° | 170°/170° |
| Refresh Rate (Hz) | 3840 Hz | 3840 Hz | 3840 Hz | 3840 Hz |
| Contrast Ratio | 10000:1 | 10000:1 | 10000:1 | 10000:1 |
| Frame Rate (Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Gray Scale (bit) | 14 | 14~16 | 14~16 | 14~16 |
| Input Voltage | AC 100V-240V, 50/60Hz | AC 100V-240V, 50/60Hz | AC 100V-240V, 50/60Hz | AC 100V-240V, 50/60Hz |
| Max Power Consumption (W/m²) | ≤400 | ≤350 | ≤350 | ≤350 |
| Average Power Consumption (W/m²) | ≤133 | ≤115 | ≤115 | ≤115 |
